The Model SEQ-QSK High Speed Transmit/Receive Sequencer is a second generation microprocessor controlled sequencer with its origins from the SEQ-1 microwave sequencer product line. A one second Heartbeat is used to give a visual indication that the SEQ-QSK is functioning properly, and four green LED's give a visual indication of the sequenced step operations. Delay times for the sequencers steps is programmable, even while in circuit. Today's Amateur operator likes the ability of fast break-in operation during contest operation, as well as during normal everyday operation. The SEQ-QSK provides this ability by allowing very high speed sequenced switching of both the Tranceiver and high power amplifier. Full VOX break-in and CW break-in operation are fast with no missed syllables, dots or dashes. Programmable delay times from 32 milliseconds to as little as 1 millisecond per step may be selected to match relays in your system. For an excellent example of an SEQ-QSK installation in a Henry 2K-4 Amplifier, visit Thomas Boza's, NE7X website here

Specifications

• 13.8 Vdc @ 50ma typical (no switched output active)
• 35 Vdc @ 600 millamperes open collector switching capability, Four outputs total
• Enable High or Enable Low input to activate sequencer
• Visual states displayed on 4 Green State LED's
• 1 second Yellow Heartbeat indicator
• Programmable delay times from 1 msec to 32 msec (default is 15 msec)
• Operating Temperature Range 0 Deg C to +70 Deg C
• Can be mounted behind a front panel, dimensions provided for mounting using 1/2" spacers
• Full 1 Year limited warranty
• Price $59.95 Assembled/Tested (plus shipping) Stock to 2 Weeks
Note: CA residence pay local Sales Tax

On-line Model SEQ-QSK Manual

Contact JWM Engineering Group, Inc. for availability and delivery schedule.
